Bag Filter Housing Manufacturer
As a leading bag filter housing manufacturer, we provide high-performance filtration solutions for industrial and commercial applications. Our bag filter housings are engineered for efficient solid-liquid separation, delivering superior particle retention with minimal pressure drop. Whether you need SS bag filter housing for chemical processing or stainless steel bag filter housing for food-grade environments, our solutions are trusted for quality, durability, and ease of maintenance.
About Our Bag Filter Housings
Our housing bag filters are designed to accommodate standard filter bags and offer reliable protection for downstream equipment. Available in various sizes, materials, and pressure ratings, these housings are suitable for a wide range of flow rates and applications. With precision welding, robust construction, and secure sealing, our stainless steel bag filter housings ensure safe and leak-free operation even under demanding process conditions.
Key Features of Bag Filter Housings
- High-capacity filtration for large flow volumes
- Quick-opening clamps or swing bolts for easy bag changeout
- Rugged construction using SS304, SS316, or SS316L
- Corrosion-resistant and chemical-resistant designs
- Single and multi-bag configurations available
- Suitable for 1 to 200-micron filter bags
- Compact footprint and easy installation
Applications of Bag Filter Housings
Our bag filter housings are widely used across industries, including:
- Water & wastewater treatment
- Chemical and petrochemical processing
- Paints, inks & dyes filtration
- Food and beverage industry
- Pharmaceutical and biotech manufacturing
- Power generation
- Metalworking fluids & lubricants
Technical Specifications of Bag Filter Housings
| Parameter |
Details |
| Housing Material |
SS304, SS316, SS316L |
| Design Pressure |
Up to 10 bar (150 psi) |
| Operating Temperature |
Up to 120°C |
| Filter Bag Size |
Size 1, Size 2, Custom sizes |
| Connection Type |
Flanged, Threaded, Tri-clamp |
| Surface Finish |
Polished / Electropolished / Matte |
| Seal Options |
EPDM, Viton, Nitrile, PTFE |
| Flow Rate Capacity |
Up to 1000 m³/hr (varies by model) |
| Inlet/Outlet Size |
1” to 6” (DN25 to DN150) |
Frequently Asked Questions (FAQs)
A bag filter housing is a pressure vessel designed to hold a filter bag. It filters solid particles from liquids in various process systems.
SS316 offers better corrosion resistance than SS304, especially in chloride or marine environments. SS316 is recommended for aggressive or sanitary applications.
Flow rates vary depending on bag size and fluid characteristics. Our housing can handle flows up to 1000 m³/hr in multi-bag configurations.
Yes, our housing bag filters are suitable for both low and high-viscosity liquids. We help in sizing the correct model for your application.
Absolutely. As a bag filter housing manufacturer, we can customize size, connections, material grades, and other specifications as per your requirements.
Routine maintenance involves changing the filter bag once clogged and inspecting the sealing and housing. Our designs ensure quick and easy changeouts.
